Two working station high speed balancing machine Weight Correction Machine

Brand Name : Nide
Model Number : BDXDR-2WIV-A
Certification : CE
Place of Origin : China
MOQ : 1 SET
Price : Negotiable
Payment Terms : T/T, L/C
Delivery Time : 60 working days
Packaging Details : Wooden case suitable for sea transportation
Condition : ew
Working station : Two
Machine power : 1.5KW
Machine weight : 1000KG
Rotor diameter : 60~90mm
Contact Now

Two working station high speed balancing machine Weight Correction Machine


Quick Detail:

1. There are 2 working stations
2. High efficiency and precision.
3. All the data can be set on the touch screen.
4.Cutting depth and length can be controlled.

Description:

This type balancing machine is equipped with two working stations. One is used for balancing, the one for balancing. Machine is simple to operat and tooling change is easy. It is of high efficiency and stable performance. Machine is equipped with touch screen, all the data can be displayed and set in it. High efficiency and precision.PLC controlled, all the data can be set on the touch screen.
Machine working station

Technical Parameter


Items



Details


TypeTwo-station(single-cutter/double-cutter)

Main

components

configuration

Cylinder: SMC

Actuating motor: Mitsubishi

Sensor: KEYENCE,OMRON,CONTRINEX

LCD Touch screen: KEYENCE

Control PLC: KEYENCE KV-1000

Stepping motor: Oriental Motor


Armature apply range

Armature below 3KG

Stack height:30-100mm

Armature diameter: Φ60-90mm

Balancing speed1500-2100rpm
Milling methodR-shape or V-shape
PowerAC380V
Air supply0.4~0.6Mpa
Initial unbalance
Cycle time15-20s

Residual unbalance

eccentricity

Better than the China national standard Grade 6.3

Volume

(length x width x height)

1700 X1000X 1550 mm mm

Maintenance of the system
A. Daily Maintenance
1. Clean the dust and ash on the surfaces of the machine, keep every part clean.
2. Ensure the power and air supply function well before starting the system.
3. Check the vulnerable components (leather conveyors, ceramic sticks, block piece, etc).
Please replace the damaged ones.


B. Monthly Maintenance
1. Check damping of every air cylinder to ensure they can function smoothly.
2. Lubricate every linear guide and bearing.
3. Add rust preventing oil on the components.
4. Add lube into the flow nipple on the cutters to lubricate the bearings.
5. Check the filters of the air compressors, dewater them regularly.
6. Check the status of the dust collector and the filter net to ensure they can function well.
l Season Maintenance
1. Demagnetize cutters and fixture seats.
2. Check if the cutters are filthy or wearing (1 sharpening/ 0.1 million uses). Check if the
screws are tightened.
3. Check the vulnerable components (leather conveyors, ceramic sticks, block piece, etc).


C.Yearly maintenance
1. Check the flexibility of the gears. Replace those that can’t function well.
2. Check if the spring pieces are out of shape. Replace those with distortions.
3. Check if the screws on the electrical vortex sensors are tightened and if the direct current
voltage between “O UT+” and “COM-” is between -1 and -2.
4. Check the fan in the electric equipment cabinet. Check the voltage of every electric circuit.
5. Check air out line of the air connector.
